6T Lion Battery Electric Pallet Lift 6000kg Counterbalance Pallet Stacker

Product Details

Place of Origin: China

Brand Name: YEAWEY

Certification: CE ISO,SGS

Model Number: CBD60

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Price: 6000-7500 usd

Packaging Details: Plastic bag

Delivery Time: 5-8 working days

Payment Terms: L/C, T/T, D/P, D/A, Western Union, MoneyGram

Supply Ability: 100 units per month

Get Best Price
Highlight:

Lion Battery Electric Pallet Lift

,

Electric Pallet Lift 6000kg

,

6000kg Counterbalance Pallet Stacker

Product Name:
6Ton Pallet Truck Standard Model
Lift Capacity:
6000kg
Battery:
Lion Battery Or Lead Acid Battery
Fork Width:
190mm
Fork Length:
1150-2200mm
Charger:
100AH
Product Name:
6Ton Pallet Truck Standard Model
Lift Capacity:
6000kg
Battery:
Lion Battery Or Lead Acid Battery
Fork Width:
190mm
Fork Length:
1150-2200mm
Charger:
100AH
6T Lion Battery Electric Pallet Lift 6000kg Counterbalance Pallet Stacker

6000kgs stand type 6T electric pallet stacker Mini Walk Electric Hydraulic Pallet Truck



Main information:
Load capacity: 6000kgs*600mm
Chinese AC controller

Lead acid battery or Lithium battery
AC motors
Lifting height 120mm
PU tires
Fork 1150/2200mm



Specification   CBD60
Power type   Electric
Driving mode   Stand-on type
Rated load kg 6000
Load center distance mm 600
Wheel base mm 1458
Vehicle weight (including battery) kg 950
Tire type, drive side / load side   Polyurethane
Tire size, load-bearing side mm Φ85*90
Tire size, drive side mm Φ230*90
Stabilizer wheel size mm Φ130*55
Number of wheels front / rear (X= drive wheel)   4/1X+8
Track width, drive side mm 654
Track width, bearing side mm 480
Lifting height mm 120
Height of station board mm 160
Minimum ground clearance of fork surface mm 95
Overall length mm 1945/2346
Overall width mm 885
Fork size mm 1200*235*82
Outside distance of fork mm 715
Ground clearance of vehicle body mm 65
Right angle stacking channel width (1000*1200 horizontal) mm 2950/2550
Turning radius mm 2150/1750
Driving speed (full/ no load) km/h 4.0/5.0
Lifting speed (full/ no load) mm/s 25/30
Descent speed (full/ no load) mm/s 29/16
Maximum climbing capacity (full/ no load) (S2-5min) % 2/8
Braking mode   Electromagnetic type
Drive motor power (S2-60min) kw 2.5
Lifting motor power (S3-15%) kw 2.2
Battery voltage/ capacity v/ah 24/280
Battery weight kg 245
Steering system   Electronic steering
Battery replacement method   Lifting type
