Product Details
Place of Origin: China
Brand Name: YEAWEY
Certification: CE ISO，SGS
Model Number: CPCG50
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: 7000-9500 usd
Packaging Details: Plastic bag
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability: 100 units per month
Product Name: |
5.0 Ton Dual Fuel Forklift |
Load Capacity: |
5000 Kg |
Load Center: |
500mm |
Lift Height: |
3000mm FFL Mast |
Width: |
1250m |
Fork Size: |
1220X150X55MM |
Service Weight: |
5500KG |
Color: |
Red And Grey |
Product Name: |
5.0 Ton Dual Fuel Forklift |
Load Capacity: |
5000 Kg |
Load Center: |
500mm |
Lift Height: |
3000mm FFL Mast |
Width: |
1250m |
Fork Size: |
1220X150X55MM |
Service Weight: |
5500KG |
Color: |
Red And Grey |
Duplex 3m 5 Ton dual fuel LPG forklift warehouse use IMPCO converter LPG tank
Main information:
Product name: 5.0Ton LPG dual fuel forklift
Engine: Chinese Guangqing or Japanese NISSAN gasoline forklift.
Transmission: Automatic
Mast type: 2 stage mast 3m lifting height
Tires: pneumatic
Fork: 1220mm-2000mm
Attachments: Side shift, double front tires
The higher-end model in of YEAWEY forklift products line, sets new bar in counter balance forklifts. It offers graceful appearance and over 55 improvements of inside and out ergonomic design, enhanced safety and performance while lowering vibration, operating noise and easy to maintain.
Working efficiency improved
Small turning radius makes steering flexible and easy.The truck has fast lifting speed, good gradeability and high efficiency.High working efficiency guarantees the truck could meet the requirements for various kinds of complicated work condition perfectly wherever at port, dock and railway station.
Ergonomic comfort
Perfect shape & position of manual gear level facilitate the drivers’ operation.Independent dual rear lights together with warning light are easy to recognize & maintain.
Great heat dissipation
The hot air reflow isolating device, optimal thermal dissipation duct and aluminum plate-fin type radiator improve cooling ability and ensure engine work reliability.
High Quality & Durable tires
Yeawey forklift front tires are a special heavy truck tire with a wide footprint giving it greater stability and lift capacity in rough work environments.
Adjustable Steering Wheel
Provide convenience and can customize to the operator's desired position.
| Specification | 5Ton Dual fuel type gasolie and LPG | ||
| 1 | Fuel model | Dual fuel | |
| 2 | Load capacity | kg | 5000 |
| 3 | Load center | mm | 500 |
| 4 | Lift height | mm | 3000 |
| 5 | Full free lift height | mm | 0 |
| 6 | Fork dimension | mm | 1070×150×50 |
| 7 | Mast tilting angle | Deg. | 6/12 |
| 8 | Min.turning radius | mm | 2680 |
| 9 | Groud clearance | mm | 135 |
| 10 | Overhead guard height | mm | 2210 |
| 11 | Front overhang | mm | 495 |
| 12 | Max travel speed | km/h | 22 |
| 13 | Max lift speed | mm/s | 330 |
| 14 | Max.traction power | KN | 18.5 |
| 15 | Max. gradeability | % | 20 |
| 16 | Total length with fork | mm | 4195 |
| 17 | Total length without fork | mm | 2975 |
| 18 | Total width | mm | 1380 |
| 19 | Mast extended height | mm | 4250 |
| 20 | Mast lowered height | mm | 2185 |
| 21 | Tyres Front | 300-15-18PR | |
| 22 | Type Rear | 700-12-10PR | |
| 23 | Wheelbase | mm | 1960 |
| 24 | Tread | mm | 1000/970 |
| 25 | Service weight | Kg | 5300 |
| 26 | Battery | V/Ah | 12/80 |
| 27 | Engine model | GQ-4Y gasoline engine | |
| 28 | Engine power | kw/r.p.m | 46 |
| 29 | Transmission | Mechanical or Automatic | |
| 30 | Work press | Mpa | 18.5 |
