3000Kgs CPD30KD Lithium Powered Forklift Chinese FANJI Electric Forklift Truck

Main information:

Load capacity: 3500kg*500mm

Lead acid battery 80V/350AH

Charger 80V/100A

Chinese FANJI controller

AC lift motor and AC drive motor

Automatic transmission

2 stage 3m mast

Pneumatic tires

Fork 1220mm

HK Series Electric Forklift Truck

With Lithium Power

HK series lithium battery forklifts are high quality products developed on the basis of the advantages of "High performance lithium battery system" and "Domestic and imported advanced controllers". The load capacity range is from 1.5Ton to 5.0Ton.

Following the family design of I.C. forklifts, they are provided with some key parts compatible with them, and optimized mainly on the overall performance, ergonomics, reliability, maintenance, outdoor operation ability and load capacity in a bid to meet customers’ different requirements.

Curtis controller

The trucks are equipped with Curtis controllers.CAN-bus technology makes the diagnostic and trouble shooting easier.The use of proved and certified components helps to ensure the conformity to international safety standards with all the supporting documents available as required by law.

AC maintenance-free drive motor

Adopt maintenance-free and powerful AC drive motor. Compared with traditional DC motors, our AC motors do not need to replace Carbon brushes. Equipped with speed sensor and temperature sensor, greatly improving the AC motor’s reliability.

High performance transmission:

Transmission system uses a horizontal fan-shaped drive axle arranged in parallel with a large transmission ratio. The battery is installed at the bottom of the frame.Traveling motor adopts AC maintenance-free motor.

Comfortable experience

The forklift was ergonomically designed and it enables a wide view and a large operation space.

The dashboard are designed to have clear and intuitive graphic interfaces.

Flexible scenarios

Smooth travel: ground clearance increased, to adapt to outdoor rough roads;

Flexible turning: turning radius reduced, to allow flexible shuttling in indoor environments such as cold store;

No fear of cold: the battery equipped with standard electric heating module, to ensure normal operation in cold weather;


Warranty:
The warranty period is 24 months from on board date or 2000 working hours whichever comes first.
During warranty, we offer air delivery of the spare parts within 2 working days.Besides that, we have experienced engineers to check the problems and maintenance.

Delivery time:
As a factory, we can offer fast products delivery, standard forklift is 7 working days, Forklift with options is 10-20 working days.
Should you have any questions pls feel free to let us know.
